Does the WK2806 actually include a Magnetic Encoder, and if so, how do I hook it up to an Arduino to read the rotation angle? If not, where do I find the correct encoder for the frameless motor.

Hello, there is no encoder on WK2806 motor, the frameless motor only include a rotor and stator.
We only have three kinds of magnetic encoders now: AS5047P, AS5048A and AS5600.

SteadyWin WK2806 Magnetic Encoder Sets PWM and SPI Interface Brushless DC Frameless Motor for Gimbal Camera

SteadyWin WK2806 Magnetic Encoder Sets PWM and SPI Interface Brushless DC Frameless Motor for Gimbal Camera

(100+ ratings)

$6.88

$10.00

WK2806

Magnetic Ring Rotor
Magnetic Disc Rotor

Quantity

Must-Read Before Ordering !!!

Q&A

Q 1 : What is the difference between the magnetic ring version and the magnetic disc version?

A : The torque of the magnetic ring version is 50% lower than that of the magnetic disc version.

Please Note：

Stator + Rotor = Frameless Motor
Frameless motors comprise only the stator and rotor components.

CAD Files Download:
WK2806 2D Drawing
WK2806 3D Model.STEP
WK2806 Magnetic Ring Rotor Type 2D Drawing
WK2806 Magnetic Ring Rotor Type 3D Model.STEP

More Information：
Frameless Outrunner Motor Selection Table

If you require additional materials, please visit: http://steadywin.cn/.
Should you be unable to find the necessary information or have any question,
please contact us at
Email：info@steadywin-motor.com
Phone/ WeChat: (+86)13077918423
WhatsApp: (+853)68619243

Feel free to contact us for any needs.
Customization is supported.

Have a nice day!
