SteadyWin GIM8108-8 Planetary reduction motor robot dog humanoid robot

Questions & Answers

Have a Question?

Ask a Question

I want to buy gim8108 for my thesis biped robot.how i use this i am using ardino mega.... Can i connect this with ardiuno or i need any controler or how can i use it kindly response its emergency

Here is an Arduino r4 debugging example based on our GDZ driver board for your reference.
arduino code example

SteadyWin GIM8108-8 Planetary reduction motor robot dog humanoid robot joint module flat thin large torque

SteadyWin GIM8108-8 Planetary reduction motor robot dog humanoid robot joint module flat thin large torque

(100+ ratings)

$93.89

$110.00

GIM8108-8 Motor

GIM8108-8 Standard Version
GWK8108-8 (without housing)
GIM8108-8 Shaft Version
GIM8108-8 Brake Version

Driver

without driver
with GDS68 driver
with GDS68 driver with 2ES68 secondary encoder
with GDZ68 driver
with GDZ68 driver with 2EZ68 secondary encoder

Quantity

Must-Read Before Ordering !!!

Q&A

Q 1 : What's the difference between GDZ468 driver and GDS68 driver?

A : The GDZ468 driver board supports three communication protocols: CAN, 485, and Modbus,
while the GDS68 drive board supports CAN communication.

Q 2 : What's the function of the secondary encoder?

A: The sole function of the secondary encoder is to remember the single-turn position after a power loss. 【 not to mitigate the backlash】

Please Note：

If you need to use our host computer software to debug the motor, the following applies:

· For the GDZ468 driver board, a USB-to-485 adapter is required (please note that some other brands may not be compatible; it is available for purchase if needed).
· For the GDS68 driver board, a Type-C cable is needed.

CAD Files Download：
GWK8108-8 2D Drawing.pdf
GIM8108-8 2D Drawing.pdf
GIM8108-8 3D Model.STEP

Document of Driver Download：
GDZ468 Driver
GDS68 Driver

More Information：
Planetary Reduction Motor Selection Table-GDZ Driver
Planetary Reduction Motor Selection Table-GDS Driver.xlsx

We apologize that some of the driver documentation is currently only available in Chinese.
If you require additional materials, please visit: http://steadywin.cn/.
Should you be unable to find the necessary information or have any question,
please contact us at
Email：info@steadywin-motor.com
Phone/ WeChat: (+86)13077918423
WhatsApp: (+853)68619243

Feel free to contact us for any needs.
Customization is supported.

Have a nice day!

Guarantee Safe
Checkout

trust_2dea69ed-7223-44f3-828d-a80bc0f3aef4

Estimate delivery times: 12-26 days (International)

After receiving the product, if there are any quality issues, please apply for a refund within 7 days of receipt.

Intelligence drives the future

Unleash the true potential of your robotic creations with the GIM8108-8 Planetary Gear Reducer – the epitome of speed, strength, and safeguarding in the world of robotics! Crafted with precision and engineered for excellence, this gear reducer is your gateway to achieving unparalleled performance and reliability in your robotic and mechanical endeavors.

With a wide voltage range stretching from 12V to a robust 56V, the GIM8108-8 offers unmatched adaptability, ensuring compatibility with a diverse array of power supplies and systems. Its operational speed range of 110-320RPM provides the perfect balance between agility and power, making it ideal for a multitude of applications, from robotic joints to mechanical dog joints, and beyond.
