SteadyWin GB8115 Small Brushless Servo Motor Hollow Flat Gimbal Servo

Questions & Answers

Have a Question?

Ask a Question

Hello I need this motor in a GB8115_4 version Thank you

Hello, that's okay.
You just need to leave a note when placing the order.
If no note is added, the default model will be GB8115-1.

Please note that the numbers 1 and 4 at the end represent resistors.
The higher the resistance, the lower the speed; the lower the resistance, the higher the speed.
Therefore, the GB8115-4 is the one with a lower speed.

SteadyWin GB8115 Small Brushless Servo Motor Hollow Flat Gimbal Servo Drone Gimbal Camera Motor

SteadyWin GB8115 Small Brushless Servo Motor Hollow Flat Gimbal Servo Drone Gimbal Camera Motor

(100+ ratings)

$78.50

$90.00

GB8115

only motor (through-hole version)
only motor
with AS5600 encoder
with AS5048A encoder

Quantity

Must-Read Before Ordering !!!

Please Note：

1. About Brushless DC Motor (Gimbal Motor)
Frameless Motor + Housing = Gimbal Motor
A Gimbal Motor ( BLDC Motor) is built from a frameless motor core.
It is designed to be used with an encoder and requires an external driver (e.g., SDC300). Typical applications include camera gimbals, rotating LiDAR, small UAV pods, and precision rotary tables.
【For GB motors, our current solution is to use an external drive.】

2. About Encoder

1) AS5600 encoder for PWM interface: Default connector type is SH1.0-3P.
2) 【Only AS5048a/AS5047p encoders are compatible with our external driver.】
3) AS5048A encoder for PWM interface: Default connector type is SH1.0-3P
(will be replaced with GH1.25-3P when used with our external driver).
4) AS5048A encoder for SPI interface: Default connector type is GH1.25-6P.

For other requirements, please contact: info@steadywin-motor.com

3. About the "only motor" option: It only includes the GB8115 motor, without rear cover or encoder.

CAD Files Download:
GB8115 2D Drawing
GB8115 3D Model (with encoder cover).STEP

More Information：
Gimbal Motor Selection Table

If you require additional materials, please visit: http://steadywin.cn/.
Should you be unable to find the necessary information or have any question,
please contact us at
Email：info@steadywin-motor.com
Phone/ WeChat: (+86)13077918423
WhatsApp: (+853)68619243

Feel free to contact us for any needs.
Customization is supported.

Have a nice day!

Guarantee Safe
Checkout

trust_2dea69ed-7223-44f3-828d-a80bc0f3aef4

Estimate delivery times: 12-26 days (International)

After receiving the product, if there are any quality issues, please apply for a refund within 7 days of receipt.

Intelligence drives the future

Experience the pinnacle of performance, efficiency, and quiet operation with the GB8115, a state-of-the-art brushless DC motor engineered to exceed expectations across industries. Whether you're automating complex processes, capturing flawless visuals, powering precision tools, enhancing smart home devices, or soaring through the skies with drones, the GB8115 delivers the reliability and power you need to succeed.

With a 24V rated voltage and a blazing-fast maximum speed of 1146RPM, the GB8115 combines speed and agility with a torque constant of 0.19Nm, ensuring smooth and responsive performance in even the most demanding applications. Its brushless design eliminates friction and wear, boosting efficiency, extending lifespan, and slashing maintenance costs.
